DS Series Heavy Duty Rigid Pipe Bar Lever Harrow
RIGID HARROW
Cultivates
and levels the ground better because of its design and rigidity. Side
rails and lever assembly are made of high carbon material for extra
rigidity.
TOOTH BARS
1 5/8 O.D. High carbon heavy duty pipe for greater strength at high speed tractor operation.
DRAW HOOKS
Designed
with the open end of the draw hook toward the ground to reduce
unhooking, This design allows for prefect trailing and the most uniform
harrowing.
TEETH
High carbon,
hammer-forged to a diamond hard point, for hard use in all soil
conditions to cultivate, pulverize, smooth and break up crust and clods.
Each tooth is reversible and replaceable. Teeth are locked on with a
lock washer and nut, and are guaranteed to outlast any other tooth of
equal weight.
LEVER ASSEMBLY
Tilts
the teeth to the angle best suited to soil and crop conditions. The
lever folds down flat for easy in handling and storage.
SPECIFICATIONS
Model
|
Description
|
No. of Teeth
|
Width
(Feet)
|
Weight
(Lbs.)
|
DS-42
|
Rigid Lever Harrow
|
40
|
5’
|
109
|
DS-43
|
Rigid Lever Harrow
|
43
|
5’ 6”
|
114
|
DS-47
|
Rigid Lever Harrow
|
47
|
6’
|
120
|
DS-51
|
Rigid Lever Harrow
|
51
|
6’ 6″
|
127
|
DS-55
|
Rigid Lever Harrow
|
55
|
7’
|
137
|
